The current page：Home > Products > Welding automation > Rotator
Products

TRZ series hydraulic assembly rotator

Feature code：
  • Normally work with TR2 series electric moving rotator for pipe pairing and welding.
  • Convenient adjustment. Each set hydraulic cylinder can work independently or simultaneously.
  • Reserved screw hole is available to be selected to adapt to workpieces with different diameters.
  • Roller base can be freely adjusted on the track to adapt to workpieces with different lengths.


Model

Load capacity
(T)

Diameter of roller (mm)

Width of roller (mm)

Diameter of workpiece (mm)

Rubber

Steel

TRZ2-5T

5

250

-

120

250～1800

TRZ2-10T

10

250

-

120

300～3000

TRZ2-20T

20

300

-

140

350～3600

TRZ2-30T

30

350

-

180

600～4200

TRZ2-40T

40

400

-

220

600～4200

TRZ2-50T

50

450

-

280

850～5000

TRZ2-60T

60

450

-

280

850～5000

TRZ2-100T

100

-

510

240

1000～5000

TRZ2-200T

200

-

600

300

1000～7500

Note: The above parameters are for TIME standard rotator configurations, and can be customized according to the customer’s requirements.
